Product Details:
|
| Customized Support: | OEM, ODM | Use: | Optical |
|---|---|---|---|
| Material: | Metal+BK7 Or Others Optical Glass,quartz,sapphire,Si,ZnSe,CaF2 Etc. | Focal Length: | +/-3000mm |
| Coating: | Upon Request | Diameter Tolerance: | +/-0.005 |
| Thickness Tolerance: | +/-0.01 | Surface Quality: | 10/5~60/40 |
| Surface Accuracy: | N=1~3 | Application Area: | Lighting,Laser Etc |
| High Light: | Cylindrical Laser Line Lens,BK7 Laser Line Lens,Optical Glass Plano Concave Lens |
||
Optical Glass BK7 Material Laser Line Lens Plano Concave Lens
A plano concave lens is an optical lens with one concave surface and one flat surface. It has a negative focal length, and can be used for light projection, beam expansion, or to increase focal length of an optical system.
Our company is a professional customized-oriented optical company.
Our main products are prisms including triangular prisms,penta prisms,roof prisms.
Lens such as plano convex,plano concave,biconvex,biconcave and so on
All this products are have kinds of sizes,shape ,welcome to inquiry
| Materials | BK7 or other optical glass,quartz,sapphire,Ge,Si,ZnSe,CaF2 etc |
| Length | 5~200mm |
| Width | 5~200mm |
| Diameter | 1.5~300mm |
| Center thickness tolerance | +/-0.01mm |
| Length tolerance | +/-0.01mm |
| Width tolerance | +/-0.01mm |
| Diameter tolerance | +/-0.0005mm |
| Surface accuracy | N=1~3 |
| Irregularity | ΔN=0.1~0.5 |
| Surface quality | 10/5~60/40 |
| Coating | Upon request |
| Application area | Imaging,Lighting,Laser etc |
machine vision, artificial intelligence, biomedical, smart city, high-end monitoring, testing instruments, military equipment, laser etching, special lighting, scientific research institutions, etc.
